ROTOR DISC » RN2833V

RN2833V

Specification

Type
Vented
Outter Ø
350
Num. of holes
5
Hole Ø:
15.8
Disc Thickness (Max)
30
Disc Thickness (Min)
27.4
Height
43.7
Centering Diameter
68
Pitch Circle Ø
114.3
Drum Ø:
156
Front/Rear
Front
Structure Material
G3000

Cross Reference

NISSAN
40206-6US0B
RENAULT
40 20 66U S0B
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

NISSAN   »   Qashqai

03.22~ 1500 KR15DDT J12E RN2833V PN2018 RN2626V PN2011

RENAULT   »   Austral

08.22~ 1200 H5F 601 HGM2 RN2833VRN1882V PN2018PN2020 RN2834VRN2626V PN2021

RENAULT   »   Espace VI

05.23~ 1200 H5F 601 RGM2 RN2833V PN2018 RN2834V PN2021

RENAULT   »   Rafale

06.23~ 1200 H5F 601 DGM2 RN2833V PN2018 RN2834V PN2021
06.23~ 1200 H5F 611 DGM4 RN2833V PN2018 RN2834V PN2021

RENAULT   »   Scenic E-Tech

11.23~ 6AM 406 HNJ1 RN2833V PN2018 PN2021
