ROTOR DISC » RN2868V

RN2868V

Specification

Type
Vented
Outter Ø
348
Num. of holes
5
Hole Ø:
13.8
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
50
Centering Diameter
70.6
Pitch Circle Ø
114.3
Drum Ø:
143
Front/Rear
Front
Structure Material
G3000

Cross Reference

CHANGAN
3501101-CR30
CHANGAN
CD569F260301-0701
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   CS95 Plus

02.23~ 2000 JL486ZQ5 SC6491 RN2868V PN8026 PN8005

CHANGAN   »   Uni-K iDD

03.22~ 1500 JL473ZQ6 SC6493 RN2868V PN8026 PN8048
