ROTOR DISC » RN2871

RN2871

Specification

Type
Solid
Outter Ø
305
Num. of holes
5
Hole Ø:
13
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
60.9
Centering Diameter
65
Pitch Circle Ø
108
Drum Ø:
200
Front/Rear
Rear
Structure Material
G3000

Cross Reference

DONGFENG
4581003
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DONGFENG   »   AX7

04.14~10.20 2000 EW10A D02 RN2870V PN8802 RN2871 PN8397PN6010 FN8003
