ROTOR DISC » RN2819V

RN2819V

Specification

Type
Vented
Outter Ø
340
Num. of holes
5
Hole Ø:
15
Disc Thickness (Max)
30
Height
46.3
Centering Diameter
68.5
Pitch Circle Ø
114.3
Drum Ø:
158
Front/Rear
Front
Structure Material
G3000
Disc Thickness (Min)
28

Cross Reference

HAVAL
3501121XGW01A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HAVAL   »   Big Dog DaGou II

02.23~ 1500 GW4B15D CC6470CF RN2819V PN6093 RN2820V PN6077

HAVAL   »   H6

09.22~ 1500 GW4B15D CC6470AH RN2819VRN2559V PN6070 RN2585 PN6068

HAVAL   »   H6S

11.22~ 1500 GW4B15D CC6470BK RN2819V PN6093 RN2820V PN6077

HAVAL   »   Raptor

10.23~ 1500 GW4B15E CC6480CW RN2819V PN6093 RN2820V PN6094PN6077

HAVAL   »   Xialong Max

05.23~ 1500 GW4B15H CC6480BT RN2819V PN6093 RN2820V PN6077

WEY   »   Mocca

03.22~ 1500 E15BD CC6490AY RN2819V PN6093 RN2820V PN6077
