ROTOR DISC » RN1525V
Specification
Type
Vented
Disc Thickness (Max)
20
Num. of holes
4
Height
40
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
252
Drum Ø:
127
Disc Thickness (Min)
18
Structure Material
G3000
Variation
Cross Reference
BENDIX
BDS1089
HI-Q
SD4803
OEM
4708241
OEM
93192978
SUZUKI
55311-61J00
SUZUKI
55311-62J01
SUZUKI
55311-62J02
SUZUKI
55311-62J10
SUZUKI
5531162J00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.07~12.14 | 1000 | K10B | RN1525V | PN9805 | DN1367 | FN2386 | ||
| 03.10~12.14 | 1200 | K12B | RN1525V | PN9805 | DN1367 | FN2386 |
| 10.08~02.11 | 1000 | K10B | A5B310 | RN1525V | PN9805 | DN1367 | FN2386 | |
| 02.11~06.12 | 1000 | K10B | XB22S LHD | RN1525V | PN9805 | DN1367 | FN2386 | |
| 10.08~07.12 | 1200 | K12B | XB32S | RN1525V | PN9805 | DN1367 | FN2386 | |
| 10.08~04.11 | 1300 | D13A | A5B413D | RN1525V | PN9805 | DN1367 | FN2386 |
| 03.04~04.08 | 1300 | M13A | RS413-3 LHD ZC11S | RN1525V | PN9805 | DN1367 | FN2386 | |
| 01.05~09.10 | 1300 | Z13DT | ZC91S EU | RN1525V | PN9805 | DN1367 | FN2386FN9969 | |
| 01.03~12.07 | 1500 | M15A | ZC21S RS415-1 RHD | RN2245VRN1525VRN1649V | PN9529PN9805 | RN1524DN1368 | PN8398FN9969 | |
| 01.05~09.10 | 1600 | M16A | EZC31S | RN1525VRN1649VRN2245V | PN9529PN9805 | RN1524DN1117 | PN8398FN9969FN0032 |
