ROTOR DISC » RN2449V
Specification
Type
Vented
Outter Ø
272
Num. of holes
5
Hole Ø:
12.7
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
40
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
150
Front/Rear
Front
Structure Material
G3000
Variation
Cross Reference
MARUTI
55311M60M00
SUZUKI
55311-70L00
SUZUKI
55311-70L00-000
SUZUKI
55311-72L00
SUZUKI
55311-72R10
SUZUKI
55311-72R10-000
SUZUKI
55311-77M01
SUZUKI
55311M60M00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.12~10.15 | 1300 | D13A | RN2449V | PN5562 | FN9801 | |||
| 10.15~ | 1300 | D13A | RN2449V | PN5562 | FN9801 | |||
| 04.12~10.15 | 1400 | K14B | RN2449V | PN5562 | FN9801 | |||
| 11.18~ | 1500 | K15B | ARL415 | RN2449V | PN9814 | FN9808 |
| 03.12~04.18 | 1400 | K14B | YZE81S LHD | RN2449V | PN5544 | FN9801 | ||
| 03.12~04.18 | 1400 | K14B | ZE81S LHD | RN2449V | PN5562 | FN9801 | ||
| 03.12~04.18 | 1400 | K14B | ZE81S RHD | RN2449V | PN5562 | FN9801 | ||
| 08.20~ | 1500 | K15BT | ARK415 LHD | RN2449V | PN9814 | FN9808 | ||
| 08.20~03.23 | 1500 | K15BT | ARK415 LHD XL7 | RN2449V | PN9814 | FN9808 | ||
| 08.20~ | 1500 | K15BT | NC22S RHD | RN2449V | PN9814 | FN9808 |
