ROTOR DISC » RN2866V

RN2866V

Specification

Type
Vented
Outter Ø
294
Num. of holes
5
Hole Ø:
14.2
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
50
Centering Diameter
65
Pitch Circle Ø
108
Drum Ø:
143
Front/Rear
Front
Structure Material
G3000

Cross Reference

GAC MOTOR
3510010CAC0000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GAC   »   GN6

12.21~12.22 1500 4A15J1 A06 RN2866V PN8008 RN2867 PN8074

GAC   »   Trumpchi GA6

08.19~12.23 1500 4A15J1 A35-ZD RN2866V PN8008 RN2735 PN8067

GAC   »   Trumpchi M6 Max

05.24~ 1500 4A15J2 A08-R RN2866V PN8008 RN2867 PN8074

GAC   »   Trumpchi M6 Pro

12.22~ 1500 4A15J2 A08-R RN2866V PN8008 RN2867 PN8074
