ROTOR DISC » RN2867

RN2867

Specification

Type
Solid
Outter Ø
297
Num. of holes
5
Hole Ø:
14.2
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
38.3
Centering Diameter
65
Pitch Circle Ø
108
Drum Ø:
158
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GAC MOTOR
3520006ADE0000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GAC   »   GN6

12.21~12.22 1500 4A15J1 A06 RN2866V PN8008 RN2867 PN8074

GAC   »   Trumpchi M6 Max

05.24~ 1500 4A15J2 A08-R RN2866V PN8008 RN2867 PN8074

GAC   »   Trumpchi M6 Pro

12.22~ 1500 4A15J2 A08-R RN2866V PN8008 RN2867 PN8074
